INTERIOR FIRE RETARDANT
COATING or SPRAY FOR ALL WOOD PRODUCTS
PLYWOOD ● LUMBER ● TIMBER
CLASSIFIED
19P5
FIRE RETARDANT COATING
SURFACE BURNING CHARACTERISTICS OF APPLIED COATING
| Surface | Douglas fir |
| Flame spread | 35 |
| Smoke developed | 95 |
| Number of preliminary coats | None |
| Rate per coat (ft2/gal) | -- |
| Number of fire retardant coats | 3 |
| Rate per coat (ft2/gal) | 330 |
| Number of overcoats | None |
| Rate per coat (ft2/gal) | -- |
| Flash point of liquid coating: | |
| Fire retarding coating - closed cup, | no flash |
|
TECHNICAL DATA INTERIOR CLASS A RATING |
|---|
PRODUCT DESCRIPTION: Aqueous Based Resin
| PRODUCT ANALYSIS | ||||
|---|---|---|---|---|
Total Solids |
31.5% | PH | 4.6 - 5.2 |
|
Weight per gallon |
9.4 lbs | Flash point | Non-Flammable |
|
Specific gravity |
1.104 | Color | Water clear at 78°F. - Slight haze at 50°F. or lower |
|
Volatability |
Non-Volatile | Solvents | Water(Contains no petroleum or derivatives of petroleum) |
|
Anti-Fungus |
excellent Resistance | Bacterial | Good Resistance |
|
Linear shrinkage |
None | Moisture Absorption | None |
|
Corrosive |
Mildly | Toxic | None (when dry) |
|
Insects, rodents, aspergilli And other types of molds |
Excellent resistance | Termites | Excellent resistance |
|
Preservative for wood |
None | Scrubability | 1000 cycles |
|
RECOMMENDED USE: Interior Class B Rating (Flame spread 35)
FLAME SAFE WOOD SAFE is a fire retardant coating. It can be used on any type of wood or porous materials, such as:
| Yellow Pine | Cedar | Cellulose Materials |
| Douglas Fir | Straw | Wall Coverings |
| Redwood | Blown Insulation | Corrugated Board |
ENVIRONMENTAL REGULATION:
This product complies will U. S. Federal Regulations concerning the use of lead in paint and hydrocarbon emissions.
QUICK REFERENCE FOR APPLYING WOOD SAFE
MATERIAL |
APPLICATION |
COVERAGE |
Interior/exterior wood
Yellow Pine, Douglas Fir, SPF, Redwood, plywood and textured plywood |
Treat before, during or after construction. Apply with sprayer head held at 8 to 12 inches from surface |
Apply three (3) coats at 330 sq. ft. per gallon with the final coverage rate of 110 sq. ft. per gallon |
INTERIOR/EXTERIOR: All surfaces to be treated must be clean
and dry. Wood Safe is water-based, clear liquid that
becomes insoluble when dry.
Wood Safe
also inhibits mold and mildew protector and repels insects. If over coating is intended, Wood Safe is an excellent primer for use under
latex paints and allows a surface to be tinted witht water based stains. Avoid wasteful runs and dripping. It should be noted that unlike some
products, materials treated with Wood Safe
requires no special cutting tools or special
fasteners. Contact parts of any equipment
should be stainless steel or plastic to prevent
chemical reaction and breakdown. Storage
may be done in polyethylene containers. |
|
|---|
CAUTION:
Product must not freeze. It must not be thinned or diluted.
OVERSPRAY:
The overspray will not harm plants or animals. Spills can be flushed with water. A rag wetted with bleach and water mix will clean up spotting.
CLEAN UP PROCEDURE:
Airless Equipment.
1. Run clear water through the system until coating is flushed out. When minor sudsing on surface stops, the system is flushed.
2. Run bleach and water mix (1 part to 4 parts) through system as solvent for cleaning any residue.
3. Repeat Step 1 if any foaming occurs in Step 2.
4. Lubricate system as specified by equipment manufacturer to combat rusting.
If two or more applications are planned in the same day, the sprayer can be kept clean by running water through the system between applications.
Brushes/Rollers.
1. Clean immediately after use.
2. Wash thoroughly with bleach and water mix (1 part to 4 parts).
SAFETY FIRST
Use approved safety devices (ropes, belts, ridge hooks, ladder, etc.) When working on steep or high areas. Take EXTREME CARE not to step on wet treated area. Surface may be slick until dry.
It is good practice to wear respirator or mask and protect hands with rubber gloves when spraying any coating or chemical. When engineered air control is not feasible, use properly maintained and properly fitted NIOSH approved respirator for solvent vapors. A dusk mask does not provide protection against vapors.
If eye contact occurs, flood with water for fifteen (15) minutes and call a physician. KEEP OUT OF REACH OF CHILDREN. DO NOT TAKE INTERNALLY.
 |
|
|---|
